Cargo Van 2500 Standard Roof 144" Wheelbase Exterior Image

Sprinter Cargo Van

Starting at $49,900 *

Color

Arctic White
Build Your Van See Inventory

Cargo Van Lineup

2024

Cargo Van 2500
MSRP
$49,900 *
Diesel Standard Output
4 Cylinder
Payload
4,211 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
100 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,211 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
319.0 cu. ft
Standing Height:
68 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,211 lbs
Seating Capacity:
2-3
Cargo Volume:
319.0 cu. ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
4,839 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
7401 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
5,359 lbs
Base Curb Weight (Front), lbs.:
1,944 lbs
Base Curb Weight (Rear), lbs.:
2,917 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
28 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
54 sqft
Turning Circle (Wall to Wall):
44 ft
Available Rear Axle Ratios****:
59%/ 41%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
68.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
68 in

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3800 rpm
Rated Torque:
295 lb-ft at 1,400 -2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$52,700 *
Diesel High Output
4 Cylinder
Payload
4,211 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
100 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,211 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
319.0 cu. ft
Standing Height:
68 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,211 lbs
Seating Capacity:
2-3
Cargo Volume:
319.0 cu. ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
4,839 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Rear), lbs.:
2,950 lbs
UVW, lbs.:
7401 lbs
Base Curb Weight (Front), lbs.:
1,967 lbs
GAWR.R, lbs.:
5,359 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
28 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Interior Height:
68 in
Tires & Load Ratings:
3086
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Center of Gravity X, in:
TBD
Rim:
ET54
Tire Track (Rear), in:
68.2 in
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
67.2 in
Available Rear Axle Ratios****:
59%/ 41%
Turning Circle (Wall to Wall):
44 ft
Loading Area:
54 sqft

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$59,400 *
Diesel High Output AWD
4 Cylinder
Payload
3,858 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
100 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
3,858 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
319 cu.ft
Seating Capacity:
3

Capacity

Payload Capacity:
3,858 lbs
Seating Capacity:
3
Cargo Volume:
319 cu.ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,192 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
7401 lbs
Base Curb Weight (Rear), lbs.:
TBD
Base Curb Weight (Front), lbs.:
TBD
GAWR.R, lbs.:
TBD
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.F (Standard), lbs.:
4409 lbs
Max. Tongue Weight, lbs.:
500 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
25 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Interior Height:
67.7 in
Tires & Load Ratings:
3086
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Center of Gravity X, in:
TBD
Rim:
ET54
Tire Track (Rear), in:
68.2 in
Tire Track (Front), in:
67.2 in
Overhang (Rear), in:
49.1 in
Overhang (Front), in:
40.2 in
Turning Circle (Wall to Wall):
519.7 m
Available Rear Axle Ratios****:
60%/ 40%
Loading Area:
54.3 sq ft

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$52,800 *
Diesel Standard Output
4 Cylinder
Payload
4,699 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
96 in
Overall Length:
234 in
Overall Width with mirrors:
96 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,699 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
223 cu. ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,699 lbs
Seating Capacity:
2-3
Cargo Volume:
223 cu. ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,291 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,391 lbs
UVW, lbs.:
7,401 lbs
Base Curb Weight (Rear), lbs.:
2,922 lbs
Max. Tongue Weight, lbs.:
750
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
104 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
60.7 in
Max. Cargo Bed Length:
104 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
51 ft
Turning Circle (Wall to Wall):
53 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
49. in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Tires & Load Ratings:
3,086
Interior Height:
79 in
Center of Gravity Y, in:
TBD

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$55,600 *
Diesel High Output
4 Cylinder
Payload
4,699 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
96 in
Overall Length:
234 in
Overall Width with mirrors:
80 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,699 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
223 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,699 lbs
Seating Capacity:
2-3
Cargo Volume:
223 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,291 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs
Base Curb Weight (Front), lbs.:
2,362 lbs
Base Curb Weight (Rear), lbs.:
3,006 lbs
UVW, lbs.:
7,401 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
104 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
49.3 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
104 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
81 sq rt
Turning Circle (Wall to Wall):
53 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
1,594 in
Center of Gravity Z, in:
770 in
Max. Height Center of Gravity Z , in:
51.2 in
Center of Gravity Y, in:
Interior Height:
79 in
Tires & Load Ratings:
3,086

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$58,500 *
Diesel High Output
4 Cylinder
Payload
5,739 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
100 in
Overall Length:
234 in
Overall Width with mirrors:
80 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
5,739 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
281 cu ft
Standing Height:
68 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
5,739 lbs
Seating Capacity:
2-3
Cargo Volume:
281 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,291 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,721 lbs
Base Curb Weight (Front), lbs.:
2,362 lbs
Base Curb Weight (Rear), lbs.:
3,006
UVW, lbs.:
10,470 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
51 sq ft
Turning Circle (Wall to Wall):
48 ft
Available Rear Axle Ratios****:
55%/ 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2,679
Interior Height:
68 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$65,200 *
Diesel High Output AWD
4 Cylinder
Payload
5,441 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
109 in
Overall Length:
234 in
Overall Width with mirrors:
80 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
5,441 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
281 cu ft
Standing Height:
68 in
Seating Capacity:
3

Capacity

Payload Capacity:
5,441 lbs
Seating Capacity:
3
Cargo Volume:
281 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,578 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
GAWR.F (Standard), lbs.:
4,409 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Option), lbs.:
GAWR.R, lbs.:
7,721 lbs
UVW, lbs.:
10,470 lbs
Base Curb Weight (Rear), lbs.:
3,255 lbs
Base Curb Weight (Front), lbs.:
2,841 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
25 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Turning Circle (Wall to Wall):
46 ft
Loading Area:
51 sq ft
Available Rear Axle Ratios****:
56%/ 44%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66.8 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Y, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Z, in:
TBD
Interior Height:
79 in
Tires & Load Ratings:
2679

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 4500
MSRP
$61,000 *
Diesel High Output
4 Cylinder
Payload
6,812 lbs
Build Cargo Van 4500

Dimensions

Overall Height:
98 in
Overall Length:
234 in
Overall Width with mirrors:
96 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
6,812 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
281 cu ft
Standing Height:
68 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
6,812 lbs
Seating Capacity:
2-3
Cargo Volume:
281 cu ft
Max Available GVWR:
12,125 lbs
Base Curb Weight:
5,313 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
11,373 lbs
Base Curb Weight (Rear), lbs.:
3,019 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,630 lbs
GAWR.F (Option), lbs.:
GAWR.R, lbs.:
7,934 lbs
Base Curb Weight (Front), lbs.:
2,372 lbs

Measurements

Standing Height:
68 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
60 in
Door Opening-Rear(Height):
61 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Turning Circle (Wall to Wall):
48 ft
Loading Area:
51 sq ft
Available Rear Axle Ratios****:
55% / 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
68 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)

2024

Cargo Van 2500
MSRP
$53,400 *
Diesel Standard Output
4 Cylinder
Payload
4,134 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,134 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
374 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,134 lbs
Seating Capacity:
2-3
Cargo Volume:
374 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
4,916 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
7401 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs
Base Curb Weight (Front), lbs.:
2,025 lbs
Base Curb Weight (Rear), lbs.:
2,914 lbs
GAWR.R, lbs.:
5,359 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
28 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
50 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
54 sqft
Turning Circle (Wall to Wall):
44 ft
Available Rear Axle Ratios****:
59%/ 41%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
68.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3800 rpm
Rated Torque:
295 lb-ft at 1,400 -2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$56,200 *
Diesel High Output
4 Cylinder
Payload
4,134 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,134 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
374 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,134 lbs
Seating Capacity:
2-3
Cargo Volume:
374 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
4,916 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Rear), lbs.:
2,996 lbs
UVW, lbs.:
7401 lbs
Base Curb Weight (Front), lbs.:
1,997 lbs
GAWR.R, lbs.:
5,359 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
28 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
50 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Interior Height:
79 in
Tires & Load Ratings:
3086
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Center of Gravity X, in:
TBD
Rim:
ET54
Tire Track (Rear), in:
68.2 in
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
67.2 in
Available Rear Axle Ratios****:
59%/ 41%
Turning Circle (Wall to Wall):
44 ft
Loading Area:
54 sqft

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$62,900 *
Diesel High Output AWD
4 Cylinder
Payload
3,781 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
111 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
3,781 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
374 cu.ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
3,781 lbs
Seating Capacity:
2-3
Cargo Volume:
374 cu.ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,269 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
7401 lbs
Base Curb Weight (Rear), lbs.:
TBD
Base Curb Weight (Front), lbs.:
TBD
GAWR.R, lbs.:
5,359 lbs
GAWR.F (Option), lbs.:
TBD
GAWR.F (Standard), lbs.:
4409 lbs
Max. Tongue Weight, lbs.:
500 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
25 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
50 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
74 in
Loading Area:
54.3 sq ft
Turning Circle (Wall to Wall):
519.7 m
Available Rear Axle Ratios****:
60%/ 40%
Overhang (Front), in:
40.2 in
Overhang (Rear), in:
49.1 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
68.2 in
Rim:
6,5J x 16
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$56,300 *
Diesel Standard Output
4 Cylinder
Payload
4,622 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
109 in
Overall Length:
234 in
Overall Width with mirrors:
92 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,622 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
329 cu ft
Standing Height:
79
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,622 lbs
Seating Capacity:
2-3
Cargo Volume:
329 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,368 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,426 lbs
UVW, lbs.:
7,401 lbs
Base Curb Weight (Rear), lbs.:
2,965 lbs
Max. Tongue Weight, lbs.:
750
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs

Measurements

Standing Height:
79
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
51 ft
Turning Circle (Wall to Wall):
48 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
49. in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3,086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$59,100 *
Diesel High Output
4 Cylinder
Payload
4,622 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
109 in
Overall Length:
234 in
Overall Width with mirrors:
80 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,622 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
329 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,622 lbs
Seating Capacity:
2-3
Cargo Volume:
329 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,368 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$62,000 *
Diesel High Output
4 Cylinder
Payload
5,662 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
109 in
Overall Length:
234 in
Overall Width with mirrors:
96 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
5,662 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
329 cu ft
Seating Capacity:
2-3

Capacity

Payload Capacity:
5,662 lbs
Seating Capacity:
2-3
Cargo Volume:
329 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,368 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,721 lbs
Base Curb Weight (Front), lbs.:
2,396 lbs
Base Curb Weight (Rear), lbs.:
3,049 lbs
UVW, lbs.:
10,470 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
50 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
51 sq ft
Turning Circle (Wall to Wall):
48 ft
Available Rear Axle Ratios****:
55%/ 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$68,700 *
Diesel High Output AWD
4 Cylinder
Payload
5,353 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
111 in
Overall Length:
234 in
Overall Width with mirrors:
96 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
5,353 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
329 cu ft
Standing Height:
79 in
Seating Capacity:
3

Capacity

Payload Capacity:
5,353 lbs
Seating Capacity:
3
Cargo Volume:
329 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,677 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
GAWR.F (Standard), lbs.:
4,409 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Option), lbs.:
TBD
GAWR.R, lbs.:
7,721 lbs
UVW, lbs.:
10,470 lbs
Base Curb Weight (Rear), lbs.:
TBD
Base Curb Weight (Front), lbs.:
TBD

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
25 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
51 sq ft
Available Rear Axle Ratios****:
56%/ 44%
Turning Circle (Wall to Wall):
46 ft
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66.8 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Y, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Z, in:
TBD
Interior Height:
79 in
Tires & Load Ratings:
2679

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 4500
MSRP
$64,500 *
Diesel High Output
4 Cylinder
Payload
6,735 lbs
Build Cargo Van 4500

Dimensions

Overall Height:
109 in
Overall Length:
234 in
Overall Width with mirrors:
96 in
Wheelbase:
144 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
6,735 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
281 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
6,735 lbs
Seating Capacity:
2-3
Cargo Volume:
281 cu ft
Max Available GVWR:
12,125 lbs
Base Curb Weight:
5,390 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
11,373 lbs
Base Curb Weight (Rear), lbs.:
3,068 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,630 lbs
GAWR.F (Option), lbs.:
GAWR.R, lbs.:
7,934lbs
Base Curb Weight (Front), lbs.:
2,410 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
133 in
Turning Diameter (curb to curb):
45 ft
Ground To First Step-Side:
22 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
133 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Turning Circle (Wall to Wall):
48 sq ft
Loading Area:
51 sq ft
Available Rear Axle Ratios****:
55% / 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
49 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)

2024

Cargo Van 2500
MSRP
$56,500 *
Diesel Standard Output
4 Cylinder
Payload
3,814 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
274 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
: 4-Cylinder Diesel Standard Output
Payload Capacity:
3,814 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
488 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
3,814 lbs
Seating Capacity:
2-3
Cargo Volume:
488 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,236 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
7401 lbs
Base Curb Weight (Rear), lbs.:
3,050 lbs
Base Curb Weight (Front), lbs.:
2,208 lbs
GAWR.R, lbs.:
5,359 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4101 lbs
GAWR.F (Option), lbs.:
4409 Ibs

Measurements

Standing Height:
79 in
Cargo Bed Length:
173 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
20 in
Load height, unloaded (ground to cargo floor):
27 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in

Powertrain

Engine:
: 4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lbf -ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$59,300 *
Diesel High Output
4 Cylinder
Payload
3,814 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
274 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
3,814 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
488 cu.ft
Standing Height:
79 in
Seating Capacity:
3

Capacity

Payload Capacity:
3,814 lbs
Seating Capacity:
3
Cargo Volume:
488 cu.ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,236 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
5,359 lbs
Base Curb Weight (Front), lbs.:
2,232 lbs
Base Curb Weight (Rear), lbs.:
3,082 lbs
UVW, lbs.:
7,401 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
20 in
Load height, unloaded (ground to cargo floor):
27 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
74 sq rt
Turning Circle (Wall to Wall):
50 ft
Overhang (Front), in:
40 in
Available Rear Axle Ratios****:
58%/ 42%
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$66,000 *
Diesel High Output AWD
4 Cylinder
Payload
3,450 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
111 in
Overall Length:
274 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
3,450 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
488 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
3,450 lbs
Seating Capacity:
2-3
Cargo Volume:
488 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,600 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,328 lbs
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,409 lbs
GAWR.F (Option), lbs.:
UVW, lbs.:
7,401 lbs
Base Curb Weight (Rear), lbs.:
3,349 lbs
GAWR.R, lbs.:
5,359 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
24.2 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
74 sq rt
Turning Circle (Wall to Wall):
53 ft
Overhang (Front), in:
40 in
Available Rear Axle Ratios****:
58%/ 42%
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$59,400 *
Diesel Standard Output
4 Cylinder
Payload
4,269 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
109 in
Overall Length:
274 in
Overall Width with mirrors:
80 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,269 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
430 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,269 lbs
Seating Capacity:
2-3
Cargo Volume:
430 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,721 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,642 lbs
UVW, lbs.:
7,401 lbs
Base Curb Weight (Rear), lbs.:
3,101 lbs
Max. Tongue Weight, lbs.:
750
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
173 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
70 sqft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3,086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$62,200 *
Diesel High Output
4 Cylinder
Payload
4,269 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
109 in
Overall Length:
274 in
Overall Width with mirrors:
80 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,269 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
430 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
4,269 lbs
Seating Capacity:
2-3
Cargo Volume:
430 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,721 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
GAWR.F (Standard), lbs.:
4,081
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs
Max. Tongue Weight, lbs.:
750 lbs
Base Curb Weight (Front), lbs.:
2,667 lbs
Base Curb Weight (Rear), lbs.:
3,131
UVW, lbs.:
7,401 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
70 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
54%/ 46%
Overhang (Front), in:
40 in
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Interior Height:
79 in
Tires & Load Ratings:
3,086

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$65,100 *
Diesel High Output
4 Cylinder
Payload
5,309 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
109 in
Overall Length:
274 in
Overall Width with mirrors:
80 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
5,309 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
430 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
5,309 lbs
Seating Capacity:
2-3
Cargo Volume:
430 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,721 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Rear), lbs.:
3,131 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.R, lbs.:
7,721 lbs
Base Curb Weight (Front), lbs.:
2,667 lbs
UVW, lbs.:
10,470 lbs
GAWR.F (Option), lbs.:
4,409 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
53 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
70 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
54% / 46%
Overhang (Front), in:
40 in
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$71,700 *
Diesel High Output AWD
4 Cylinder
Payload
5,000 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
111 in
Overall Length:
274 in
Overall Width with mirrors:
96 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
5,000 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
430 cu ft
Standing Height:
79 in
Seating Capacity:
3

Capacity

Payload Capacity:
5,000 lbs
Seating Capacity:
3
Cargo Volume:
430 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,721 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Rear), lbs.:
3,359 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,409 lbs
GAWR.F (Option), lbs.:
TBD
UVW, lbs.:
10,470 lbs
Base Curb Weight (Front), lbs.:
2,748 lbs
GAWR.R, lbs.:
7,721 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
53 ft
Ground To First Step-Side:
24.3 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
70 sq ft
Turning Circle (Wall to Wall):
53 ft
Available Rear Axle Ratios****:
55% / 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity Z, in:
770 in
Center of Gravity X, in:
1,449 in
Max. Height Center of Gravity Z , in:
51.2 in
Center of Gravity Y, in:
Interior Height:
79 in
Tires & Load Ratings:
2679

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 4500
MSRP
$67,600 *
Diesel High Output
4 Cylinder
Payload
6,382 lbs
Build Cargo Van 4500

Dimensions

Overall Height:
109 in
Overall Length:
274 in
Overall Width with mirrors:
96 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
6,382 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
430 cu ft
Standing Height:
79 in

Capacity

Payload Capacity:
6,382 lbs
Seating Capacity:
2-3
Cargo Volume:
430 cu ft
Max Available GVWR:
12,125 lbs
Base Curb Weight:
5,743 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
UVW, lbs.:
11,373 lbs
Base Curb Weight (Rear), lbs.:
3,259 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,630 lbs
GAWR.F (Option), lbs.:
Base Curb Weight (Front), lbs.:
2,561 lbs
GAWR.R, lbs.:
7,934lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
174 in
Turning Diameter (curb to curb):
53 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
174 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
70 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
54% / 46%
Overhang (Front), in:
40 in
Overhang (Rear), in:
64 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)

2024

Cargo Van 2500
MSRP
$58,900 *
Diesel Standard Output
4 Cylinder
Payload
3,704 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
290 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
3,704 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
533 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
3,704 lbs
Seating Capacity:
2-3
Cargo Volume:
533 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,346 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,416 lbs
UVW, lbs.:
7401 Ibs
Base Curb Weight (Rear), lbs.:
2,954 lbs
Max. Tongue Weight, lbs.:
500 Ibs
GAWR.F (Option), lbs.:
4409 Ibs
GAWR.F (Standard), lbs.:
4101 Ibs
GAWR.R, lbs.:
5359 Ibs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
20 in
Load height, unloaded (ground to cargo floor):
27 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
81 sq ft
Turning Circle (Wall to Wall):
50 ft
Available Rear Axle Ratios****:
55% / 45%
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
68.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Interior Height:
79 in
Tires & Load Ratings:
3086

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lbf-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$61,700 *
Diesel High Output
4 Cylinder
Payload
3,704 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
107 in
Overall Length:
290 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
3,704 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
533 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
3,704 lbs
Seating Capacity:
2-3
Cargo Volume:
533 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,346 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
500 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
5,359 lbs
Base Curb Weight (Rear), lbs.:
3,037 lbs
UVW, lbs.:
7,401 lbs
Base Curb Weight (Front), lbs.:
2,384 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
20. in
Load height, unloaded (ground to cargo floor):
27 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
81 sq ft
Turning Circle (Wall to Wall):
50 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
68.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 2500
MSRP
$68,400 *
Diesel High Output AWD
4 Cylinder
Payload
3,351 lbs
Build Cargo Van 2500

Dimensions

Overall Height:
111 in
Overall Length:
290 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
3,351 lbs
Cargo Volume:
533 cu ft
Seating Capacity:
3

Capacity

Payload Capacity:
3,351 lbs
Seating Capacity:
3
Cargo Volume:
533 cu ft
Max Available GVWR:
9,050 lbs
Base Curb Weight:
5,699 lbs
Max Available GCWR:
13,930 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Shipping Weight:
GAWR.F (Standard):
4,409 lbs
GAWR.F (Option):
GAWR.R:
5,359 lbs
Base Curb Weight (Front):
3,274 lbs
Base Curb Weight (Rear):
2,480 lbs
UVW:
7,401 lbs
Max Tongue Weight:
500 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
24 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
53 in
Max Width at Floor:
70 in
Loading Area:
81 sq ft
Turning Circle (Wall to Wall):
53 ft
Available Rear Axle Ratios****:
56%/ 44%
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
67.8 in
Tire Track (Rear), in:
68.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$61,800 *
Diesel Standard Output
4 Cylinder
Payload
4,148 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
108 in
Overall Length:
290 in
Overall Width with mirrors:
80 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel Standard Output
Payload Capacity:
4,148 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
469 cu ft
Standing Height:
79 in

Capacity

Payload Capacity:
4,148 lbs
Seating Capacity:
2-3
Cargo Volume:
469 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,842 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,101 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
5,359 lbs
Base Curb Weight (Front), lbs.:
2,416 lbs
Base Curb Weight (Rear), lbs.:
2,953 lbs
UVW, lbs.:
7,401 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
81 sq ft
Turning Circle (Wall to Wall):
50 ft
Available Rear Axle Ratios****:
TBD
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
66.5 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3,086
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel Standard Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
170 hp at 3,800 rpm
Rated Torque:
295 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500
MSRP
$64,600 *
Diesel High Output
4 Cylinder
Payload
4,148 lbs
Build Cargo Van 3500

Dimensions

Overall Height:
108 in
Overall Length:
290 in
Overall Width with mirrors:
92 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
4,148 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
469 cu ft
Standing Height:
79 in

Capacity

Payload Capacity:
4,148 lbs
Seating Capacity:
2-3
Cargo Volume:
469 cu ft
Max Available GVWR:
9,990 lbs
Base Curb Weight:
5,743 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
GAWR.F (Option), lbs.:
4,409 lbs
GAWR.R, lbs.:
7,059 lbs
Base Curb Weight (Front), lbs.:
2,841 lbs
UVW, lbs.:
7,401 lbs
Base Curb Weight (Rear), lbs.:
3,078 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
78 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
51%/ 49%
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
65.2 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Center of Gravity Y, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Tires & Load Ratings:
2,679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$67,500 *
Diesel High Output
4 Cylinder
Payload
5,188 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
108 in
Overall Length:
290 in
Overall Width with mirrors:
96 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
5,188 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
469 cu ft
Standing Height:
79 in
Seating Capacity:
2-3

Capacity

Payload Capacity:
5,188 lbs
Seating Capacity:
2-3
Cargo Volume:
469 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
5,842 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Rear), lbs.:
3,078 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4081 lbs
GAWR.F (Option), lbs.:
4409 Ibs
GAWR.R, lbs.:
7,721 lbs
Base Curb Weight (Front), lbs.:
2,841 lbs
UVW, lbs.:
10,470 lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
53 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
29 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
80.1` sq ft
Turning Circle (Wall to Wall):
629.9 m
Available Rear Axle Ratios****:
51% / 49%
Overhang (Front), in:
40.2 in
Overhang (Rear), in:
79.6 in
Tire Track (Front), in:
67.2 in
Tire Track (Rear), in:
65.2 in
Rim:
ET54
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
3197
Interior Height:
79.1 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 3500XD
MSRP
$74,200 *
Diesel High Output AWD
4 Cylinder
Payload
4,879 lbs
Build Cargo Van 3500XD

Dimensions

Overall Height:
108 in
Overall Length:
290 in
Overall Width with mirrors:
96 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output AWD
Payload Capacity:
4,879 lbs
Max Towing:
5,000 lbs [2]
Cargo Volume:
469 cu ft
Standing Height:
79.1 in
Seating Capacity:
3

Capacity

Payload Capacity:
4,879 lbs
Seating Capacity:
3
Cargo Volume:
469 cu ft
Max Available GVWR:
11,030 lbs
Base Curb Weight:
6,151 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
5,000 lbs [2]
Fuel Tank Capacity:
24.5 gal
GAWR.F (Option), lbs.:
4,409 lbs
Base Curb Weight (Rear), lbs.:
3,078 lbs
GAWR.F (Standard), lbs.:
4,081 lbs
Max. Tongue Weight, lbs.:
500 lbs
UVW, lbs.:
10,470 lbs
Base Curb Weight (Front), lbs.:
2,841 lbs
GAWR.R, lbs.:
7,721 lbs

Measurements

Standing Height:
79.1 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
52 ft
Ground To First Step-Side:
24.3 in
Load height, unloaded (ground to cargo floor):
31 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189 in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
78 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
52% / 48%
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
66.8 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Y, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Z, in:
TBD
Tires & Load Ratings:
2,679

Powertrain

Engine:
4-Cylinder Diesel High Output AWD
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)
Cargo Van 4500
MSRP
$70,000 *
Diesel High Output
4 Cylinder
Payload
6,250 lbs
Build Cargo Van 4500

Dimensions

Overall Height:
108 in
Overall Length:
290 in
Overall Width with mirrors:
96 in
Wheelbase:
170 in

Key Features

Engine:
4-Cylinder Diesel High Output
Payload Capacity:
6,250 lbs
Max Towing:
7,500 lbs [2]
Cargo Volume:
469 cu ft
Standing Height:
79 in

Capacity

Payload Capacity:
6,250 lbs
Seating Capacity:
2-3
Cargo Volume:
469 cu ft
Max Available GVWR:
12,125 lbs
Base Curb Weight:
5,875 lbs
Max Available GCWR:
15,250 lbs
Max Towing:
7,500 lbs [2]
Fuel Tank Capacity:
24.5 gal
Base Curb Weight (Front), lbs.:
2,857 lbs
UVW, lbs.:
11,373 lbs
Base Curb Weight (Rear), lbs.:
3,095 lbs
Max. Tongue Weight, lbs.:
750 lbs
GAWR.F (Standard), lbs.:
4,630 lbs
GAWR.F (Option), lbs.:
GAWR.R, lbs.:
7,934lbs

Measurements

Standing Height:
79 in
Cargo Bed Length:
189 in
Turning Diameter (curb to curb):
53 ft
Ground To First Step-Side:
21 in
Load height, unloaded (ground to cargo floor):
28 in
Door Opening-Side(Height):
72 in
Door Opening-Rear(Height):
73 in
Dual Door Width-Side:
51 in
Door Width-Rear:
61 in
Max. Cargo Bed Length:
189in
Cargo Width at Wheelhouse:
39 in
Max Width at Floor:
70 in
Loading Area:
78 sq ft
Turning Circle (Wall to Wall):
55 ft
Available Rear Axle Ratios****:
51% / 49%
Overhang (Front), in:
40 in
Overhang (Rear), in:
80 in
Tire Track (Front), in:
66 in
Tire Track (Rear), in:
60.7 in
Rim:
HMA 125,5
Center of Gravity X, in:
TBD
Center of Gravity Z, in:
TBD
Max. Height Center of Gravity Z , in:
TBD
Center of Gravity Y, in:
TBD
Tires & Load Ratings:
2679
Interior Height:
79 in

Powertrain

Engine:
4-Cylinder Diesel High Output
Fuel Type:
Diesel
Displacement:
1950 cc
Horsepower:
211 hp at 3,800 rpm
Rated Torque:
332 lb-ft at 1,400-2,400 rpm
Transmission:
Automatic Transmission, 9G-TRONIC
Drive Shaft:
RWD
Emission Certification:
SULEV
Injection:
Common-rail direct injection (CDI)

Key Features

Standard Features

Optional Features

Standard Features

Optional Features

Standard Features

Optional Features

Special Offers

To help drive your business forward.

See All Offers

2022 Sprinter Van
Get 4.90% APR Financing up to 36 months. [3]
For a limited time, take advantage of 4.90% APR financing on a new 2022 Mercedes-Benz Sprinter Van. Offer valid through April 1, 2024.
I’m Interested

Offer Details

Only valid on 2022 Mercedes-Benz Sprinter Cargo Van, Crew Van and Cab Chassis (excluding Sprinter 4x4/AWD Cargo Van, AWD Crew Van, and all Passenger Van models). Qualified commercial customers only. 4.90% APR financing for 36 months at $29.93 per month, per $1,000 financed. Excludes leases and balloon contracts and National Fleet customers. Available only at participating authorized Mercedes-Benz Vans dealers through Mercedes-Benz Financial Services (MBFS). Must take delivery of vehicle by April 1, 2024. Specific vehicles are subject to availability and may have to be ordered. Subject to credit approval by MBFS. Actual rates, terms, down payment, and program eligibility will be determined by MBFS Credit Team based upon creditworthiness of customer. Program rates or terms may be changed or the program may be terminated at any time at the sole discretion of MBFS. To qualify, the total amount financed cannot exceed 110% of MSRP. See your authorized Mercedes-Benz Vans dealer for complete details on this and other finance offers. Offer valid through April 1, 2024.

More Than a Van

Uniformed worker accessing parts bin in upfitted van.

Upfit Your Van with Mercedes-Benz ExpertSOLUTIONS

No van upfits like a Mercedes-Benz Sprinter van. Whether for business or pleasure, Mercedes-Benz vans offer superior capabilities designed to fit your needs, no matter what they may be.

Learn More
Interior view of van showing Mercedes PRO welcome screen.

Connected Technology for Your Sprinter

With technology like Active Brake Assist, rear-view camera display, multimedia touch-screen control and more, you’ll be taking to the road with ease. And when you connect drivers, vehicles, and managers with Mercedes me connect, you can push your business even further.[4][5]

Learn More

Gallery
